穀物（主に玄米、白米）供給用に開発された高精度供給シャッターです。
被計量物の流れ具合により外側より簡単に流量調整が可能です。
Features
- The HS-8300 shutter is by 3-step control with AC solenoid. Two-step control is also possible by combination with a two-step control board.
- The HS-9100 shutter is by gate control by air. It is suitable for automatic control of a scale with large weighing capacity such as FSD-1000 type Flex-con.
仕様
| Model | HS-8300 | HS-9100 |
|---|---|---|
| Capability | 4 t/hr (when weighing 30 kg white rice) | 12 t/hr (when weighing 1 ton white rice) |
| Control method | Three-step control | Two-step control |
| Driving method | AC solenoid | Air cylinder |
| Air source | 0.4MPa（10L/min） | |
| Power supply | AC100V | AC100V |
| Weight | 30kg | |
| Option | 3-step control panel Weighing part | Sample Extraction DeviceFilter/Regulator |
